BPZK01 Digital Pressure Gauge Introduction: The BP-ZK01 digital pressure/differential pressure gauge is a versatile measurement and control device that combines precise pressure/differential pressure measurement, clear display, programmable point control, and convenient transmission output. It can be easily installed at the pressure measurement point or integrated into a control panel for testing purposes. It offers user-friendly parameter settings such as zero value, full scale value, and contact pressure value through its intuitive keypad interface
Product Features: 1. Accurate measurement
2. Automatic control
3.Rapid response
4.Multiple output signals
5.Programmability
Applications:
1. Measurement and control of pressure/differential pressure of fluid media in industries such as hydropower, metallurgy, and chemical engineering,
for automatic control applications | Performance Parameters |
| Measurement Range | -100kPa…0kPa ~ 10kPa…100MPa |
| 0-10KPa~2MPa(Differential Pressure) |
| Pressure Type | Gauge Pressure, Absolute Pressure, Sealed Pressure,Differential Pressure |
| Overload | ≤ 1.5 times of the rated range |
| Accuracy @ 25ºC | ±0.25% (Typical) ±0.5% (Maximum) |
| Long-Term Stability | ±0.3%F.S/year |
| Zero Point Temperature Drift | ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa) |
| Full Scale Temperature Drift | ±0.03%F.S/ºC(≤100KPa) ±0.02%F.S/ºC(>100KPa) |
| Compensation Temperature | 0-50ºC(0-10KPa, 0-20KPa) ,0-70ºC ,-10-70ºC |
| Operating Temperature | -20ºC~80ºC |
| Storage Temperature | -40ºC~120ºC |
| Housing Material | 304 |
| Diaphragm Material | 316L |
| Insulation Resistance | 100MΩ 100VDC |
| Relay Control | 1 to 4-channel control |
| Contact Life | Exceeds 100,000 cycles |
| Display Range | -1999~9999 |
| Installation Method | vertical axis installation |
| Explosion-proof Rating | Intrinsically Safe |
| Protection Rating | IP65 |
| Weight | ~0.5kg |
| Output Signal | Supply Voltage | Output Type |
| 4~20mA | 24VDC or 220VAC | 3 wire |
Here are some considerations when ordering a pressure controller:
1.Measurement range: Determine the required pressure measurement range to ensure that the measurement range of the selected pressure controller meets the requirements of the application.
2. Accuracy requirements: Understand the accuracy requirements of the pressure controller for the application and select a device with sufficient accuracy.
3. Output signal type: Determine the type of output signal required, such as analog (e.g., 4-20mA) or digital (e.g., RS485), in order to connect to other devices.
4. Power requirements: Understand the power requirements of the pressure controller and ensure that the appropriate power supply can be provided.
5. Installation method: Consider the installation method of the pressure controller, such as mounting directly on the measuring point or mounting on the control panel.
6. Environmental adaptability: Understand the operating environment requirements of the pressure controller, including temperature, humidity, protection level, etc., and ensure that the selected equipment can adapt to these environmental conditions.
7. Programmable function: If parameters need to be set and adjusted according to application requirements, make sure to select a pressure controller with programmable function.
| Order Guide |
| BPZK | Pressure Transmitter |
| | Code | Outline Construction |
| 01 | Digital Pressure Gauge |
| | Measurement Range | -0.1. . .0~0.01...100MPa |
| | Code | Power Supply |
| D1 | 24VDC |
| D2 | 220VAC |
| | Code | Output Signal |
| S1 | 4~20mADC | S2 | 0~10mADC |
| S3 | RS485 |
| | Code | Output function |
| S5 | One-channel relay |
| S6 | Two-channel relay |
| S7 | Three-channel relay |
| S8 | Four-channel relayF |
| S9 | Four-channel relay with RS485 |
| | Code | Pressure Connection |
| J1 | M20×1.5 |
| J2 | G1/2 Male |
| J3 | G1/4 Male |
| J4 | Other |
| | Code | Pressure Type |
| G | Gauge Pressure |
| A | Absolute Pressure |
| S | Sealed Reference Pressure |
FAQ: 1. Q: What are the features of your pressure sensor transmitters? A: High precision, durability, and excellent performance. Customization available. 2. Q: Can I customize special specifications? A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service 3. Q: What is your production capacity? A: Our manufacturing facilities can produce up to 30,000 pressure sensor transmitters per month, so we are fully capable of meeting the needs of large-scale orders. However, it is advisable to contact our sales team in advance to ensure smooth production and delivery scheduling. 4. Q: What's the typical delivery period? A: 5~8 working day for standard models. Customized products may vary. 5. Q: How are the products priced? Any discounts? A: Competitive pricing with discounts for bulk orders or long-term partners. 6. Q: What is the warranty of your products? And after-sales service? A: Our warranty time is 24 months after shipment, and our after-sales will respond with your questions in 24hrs, remote instruction by PC network is always available.
